PC SD110C
PRODUCT DETAILS
PC SD110C Material Performance Description
PC SD110C is a high-transparency, high-toughness polycarbonate material developed by Su Master New Materials (Guangdong) Co., Ltd.. It offers excellent impact resistance, high heat resistance, outstanding clarity, and strong mechanical performance. This grade is ideal for optical components, protective housings, lighting parts, and applications requiring high strength and transparency.
✅ Key Physical, Mechanical & Thermal Properties
| Property | Test Standard | Condition | Unit | PC SD110C |
|---|---|---|---|---|
| Specific Gravity | ISO 1183 | 23℃ | g/cm³ | 1.20 |
| Shrinkage Rate | ISO 294 | — | % | 0.5–0.7 |
| Melt Index | ISO 1133 | 300℃ / 1.2kg | g/10min | 10 |
| Rockwell Hardness (M) | ASTM D785 | — | — | 77 |
| Tensile Strength | ISO 527 | 50mm/min | MPa | 65 |
| Elongation at Break | ISO 527 | 50mm/min | % | 75 |
| Izod Impact Strength (Notched) | ISO 180 | 23℃ | KJ/m² | 75 |
| Heat Deflection Temperature | ISO 75 | 1.8MPa | ℃ | 127 |
| Fire Rating | UL94 | 0.75mm | — | V2 |
✅ Recommended Injection Molding Conditions
- Pre-drying Temperature: 110–120℃
- Pre-drying Time: 2–4 hours
- Melting Temperature: 250–290℃
- Mold Temperature: 70–120℃
The above technical data are reference values only and are not guaranteed. Users must verify material suitability based on actual processing and application requirements.
