PETG SD100G
PRODUCT DETAILS
SD100G Material Performance Description
SD100G is a high-transparency engineering material produced by Su Master New Materials (Guangdong) Co., Ltd.. With excellent optical clarity, balanced mechanical strength, and stable thermal performance, it is ideal for injection molding applications requiring high transparency and good dimensional stability.
✅ Key Physical, Mechanical & Optical Properties
| Property | Test Standard | Condition | Unit | SD100G |
|---|---|---|---|---|
| Specific Gravity | GB/T 1033 | — | g/cm³ | 1.27 |
| Melt Index | GB/T 3682 | 230℃ / 3.8kg | g/10min | / |
| Tensile Strength | GB/T 1040 | 10mm/min | MPa | 49 |
| Elongation at Break | GB/T 6344 | 10mm/min | % | / |
| Flexural Strength | GB/T 9341 | 2mm/min | MPa | 67 |
| Flexural Modulus | GB/T 9341 | 2mm/min | MPa | 1890 |
| Izod Impact Strength (Notched) | GB/T 1843 | 1/8 inch | KJ/㎡ | 7 |
| Light Transmittance | GB/T 2410 | 3mm | T(C) | 90 |
| Haze | GB/T 2410 | 3mm | H(C) | 1 |
| Heat Deflection Temperature | GB/T 1634 | 1.8MPa | ℃ | 62 |
| Fire Rating | GB/T 2048 | mm / 1.5min | — | HB |
✅ Recommended Injection Molding Conditions
- Pre-drying Temperature: /
- Pre-drying Time: /
- Melting Temperature: /
- Mold Temperature: /
Note: All technical indicators are provided for reference only and should not be regarded as guaranteed values. Users must verify material suitability according to their specific processing and application requirements.
