PC SD2407C
PRODUCT DETAILS
PC SD2407C Material Performance Description
PC SD2407C is a high-transparency, high-impact polycarbonate material developed by Su Master New Materials (Guangdong) Co., Ltd.. This grade delivers excellent optical clarity, high mechanical strength, stable heat resistance, and good processability. It is widely used in lighting products, electronic housings, transparent covers, and structural components requiring durability and clarity.
✅ Key Physical, Mechanical, Optical & Thermal Properties
| Property | Test Standard | Unit | PC SD2407C |
|---|---|---|---|
| Specific Gravity | ISO 1183 | g/cm³ | 1.20 |
| Shrinkage Rate (Vertical) | ISO 294 | % | 0.7 |
| Shrinkage Rate (Flow) | ISO 294 | % | 0.65 |
| Melt Index | ISO 1133 | g/10min | 20 |
| Ball Indentation Hardness | ISO 2039 | N/mm² | 116 |
| Tensile Strength | ISO 527 | MPa | 66 |
| Elongation at Break | ISO 527 | % | 65 |
| Flexural Strength | ISO 178 | MPa | 98 |
| Light Transmittance | ISO 13468 | % | 89 |
| Flame Rating | UL94 | — | V2 |
✅ Recommended Injection Molding Conditions
- Nozzle Temperature: 290–300℃
- Melting Temperature: 280–320℃
- Mold Temperature: 80–120℃
All technical data above are reference values only and not guaranteed. Users must verify suitability based on actual processing conditions and application requirements.
